Deye 15kW Hybrid Inverter (Three Phase) – SUN-15K-SG05LP3-EU-SM2
R 28,011.00 Incl VAT
- ✓ Delivery within 2-4 days
- ✓ Hassle-Free Returns for 30 days
Need help choosing the right product?
Speak to our friendly Customer Support team below.
💬 WhatsApp Us ⭐ View our HelloPeter ReviewsTechnical specifications :
- 230V/400V three-phase pure sine wave inverter
- Max PV input power : 24000W
- MPPT voltage range : 160 – 650Vdc
- Max PV input current (Imp) : 36A + 36A
- Max PV input Short-Circuit current (Isc) : 54A + 54A
- No. of MPPT : 2
- No. of strings per MPPT : 2
- Rated AC input : 15000W
- Max AC input : 16500W
- Rated AC input/output current (A) : 22.8/21.8A
- Max AC input/output current (A) : 25/24A
- Power factor : 0.8
- Max Efficiency : 97.6%
-
Battery Type : Lead-acid OR Lithium-ion
IP rating :
- IP65
Certification :
-
Grid Regulation : IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002, OVE-Richtlinie R25, G99, VDE-AR-N 4105
-
Safety / EMC Standard : IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
Protection :
DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection,
AC Output Overvoltage Protection, AC Output Short Circuit Protection, DC Component Monitoring, Arc Fault Circuit Interrupter (optional), Anti-islanding Protection, DC Switch,
Insulation Impedance Detection, Residual Current Detection.
Features :
- Dual MPPT inputs
- Dual battery inputs
-
Support storing energy from diesel generator (dedicated connectors)
-
Communication Interface : RS485/RS232/CAN
-
Monitor Mode : GPRS/WIFI/Bluetooth/4G/LAN (wifi dongle included)
-
Max. charging/discharging current of 350A
-
6 time periods for battery charging/discharging
-
AC couple to retrofit existing solar system
-
Max. 10 pcs parallel installation
Dimensions :
-
456×750×268.5 (Excluding Connectors and Brackets)
- 51.9kg
What’s in the box :
- 1 x 2 meter LAN-cable for parallel communication
- 1 x 3 meter battery temperature sensor + 10 screws
- 3 x 100A/5-mA split core sensor clamps (4m cable)
- Wifi dongle
- 11 x magnetic rings for wires.
- Wall-mounting bracket
- 4 x mounting bolts
- MC4 disconnect tool
- 4 x sets MC4-connectors
- User Manual
